Qingdao Crown Chemica_insoluble sulfur_petroleum resin_ functional resin-

Nylon 66 / Polyester cord / PA56

DETAILED DESCRIPTION

PET Tire Cord	Twist No. TPM	Breaking strength kg	Breaking elongation %	EASL %-at 4.5kg	EASL %-at 6.8kg	EASL %-at 9.0kg	EASL %-at 10.2kg	Hot air shrinkage %	Gauge mm	DPU %	Adhesive Kg/End
1000D/2	460±20	Target 15.4 ≥14.0	14.5±2.5	4.5±0.5	/	/	/	≤2.0	0.55±0.05	2.5±1.0	≥14.0
1300D/2	380±20	Target 20.0 ≥18.0	14.5±2.5	/	4.5±0.5	/	/	≤2.0	0.63±0.05	2.5±1.0	≥16.0
1500D/2	380±20	Target 23.0 ≥21.5	14.5±2.5	/	/	/	/	≤2.0	0.63±0.05	2.5±1.0	≥18.0
2000D/2	280±20	Target 30.0 ≥27.0	14.5±2.5	/	/	5.5±0.5	/	≤2.0	0.74±0.05	2.5±1.0	≥19.0
1000D/3	370±20	Target 23.0 ≥21.5	14.5±2.5	/	4.5±0.5	/	/	≤2.0	0.65±0.05	2.5±1.0	≥18.0
1500D/3	300±20	Target 34.0 ≥31	14.5±2.5	/	/	/	4.5±0.5	≤2.0	0.80±0.05	2.5±1.0	≥19.0

Nylon 66 Tire Cord	Twist No. TPM	Breaking strength kg	Breaking elongation %	EASL %-at 4.5kg	EASL %-at 6.8kg	EASL %-at 9.0kg	EASL %-at 10.2kg	Hot air shrinkage %	Gauge mm	DPU %	Adhesive Kg/End
840D/2	460±20	≥14.0	23±4	9.0±2.0	/	/	/	≤4.5	0.55±0.03	5.5±1.0	≥13.0
1260D/2	370±20	≥21.0	23±4	/	9.0±2.0	/	/	≤4.5	0.66±0.03	5.0±1.0	≥18.0
1680D/2	320±20	≥27.5	23±4	/	/	9.0±2.0	/	≤4.5	0.76±0.03	5.0±1.0	≥18.0
1890D/2	300±20	≥31.0	23±4	/	/	/	9.0±2.0	≤4.5	0.82±0.03	4.5±1.0	≥18.0

PA56 Tire Cord	Twist No. TPM	Treated Twist S (T/cm)	Treated Twist Z (T/cm)	Gauge mm	Breaking strength (N)	Elongation at Break %	Elongation at 44.1N	Shrinkage 160 ℃. 2min.0.05g/dtex %	Adhesion(H-Test) (151℃.25min.)N/10mm	Solid Content %	Warp/Weft Density rope/10cm	Width
840D/2	460±20	45±2	45±2	0.50±0.1	≥141	23±4	9±0.5	4±1	152±10	5±0.1	94/12	145.0
